For using this USB to UART Converter you need a software tool.

#Actia usb com board driver Pc

Plug your USB to TTL converter into your PC USB port.We will show you some at commands for GSM.Check for a list of the available AT commands here.Returns the product identification information: “SIM808 R14.18 OK” Returns the TA Revision Identification of Software Release of the module: “Revision:1418B03SIM808M32 OK” Enter “ AT+GMR” and press button Send.Returns the TA Model Identification of the module: “SIMCOM_SIM808 OK” Enter “ AT+GMM” and press button Send.

#Actia usb com board driver serial number

Returns the TA Serial Number Identification (IMEI) of the module: “865067024419031 OK”

Enter “ AT+GSN” and press button Send.

Returns the Manufacturer Identification of the module: “SIMCOM_Ltd OK”

Enter “ AT+GMI” and press button Send.

First you need to check if AT commands are working - enter “ AT” and press button Send.This would print OK which signifies of working connection and operation of the module.

Open the Serial Monitor at a baud rate of 9600.

Verify and upload the ATsetupsketch to your Adruino Uno.

Plug your Adruino Uno board into your PC and select the correct board and com port.

If the power supply, GSM, Bluetooth, GPS antennas and SIM card connected to the module correctly, the LED will be flash slowly (1 second on, 3 seconds off), that indicates that the module is registered to the network, and you can make a call or do something else. One of them starts to flash (1 second on, 1 second off) - SIM808 begins to work. Status indication LEDs (NET, STA, PPS) will be ON. When the module powered on, the LED power on indication (PWR) will be ON. Push the power switch to ON position - towards the SIM808 IC.

#Actia usb com board driver Bluetooth

You can power up GSM GPRS GPS Bluetooth module with power supply adapter (5-26VDC 2A) DC044 interface, with V_IN pin (5-26VDC 2A) and with Lithium Ion battery 3,5-4VDC.Insert a valid unlocked SIM card to SIM card slot of GSM GPRS GPS Bluetooth module.Attach GSM, GPS and Bluetooth antennas to GSM GPRS GPS Bluetooth module.Configuring the GSM GPRS GPS Bluetooth module with Arduino board. The mode support charge function (Default is closed).ġ. power control level) uplink/downlink data rates and GPRS configuration (e.g. In this case, power consumption is related with network settings (e.g.

There is GPRS data transfer (PPP or TCP or UDP) in progress. In this case, power consumption depends on network settings and GPRS configuration.

Module is ready for GPRS data transfer, but no data is currently sent or received. In this case, the power consumption depends on network settings such as DTX off/on, FR/EFR/HR, hopping sequences, antenna. Connection between two subscribers is in progress. Module registered to the GSM network, and the module is ready to communicate. In sleep mode, the module can still receive paging message and SMS. In this case, the current consumption of module will reduce to the minimal level. Module will automatically go into sleep mode if the conditions of sleep mode are enabling and there is no on air and no hardware interrupt (such as GPIO interrupt or data on serial port).
